ARA7615V2T2

Arrma Infraction BLX All-Road Truck, RTR, Silver, ARA7615V2T2

$1,199.99
In stock
up
down

Take high-speed street bashing performance to another level with the 1/7 scale ARRMA® INFRACTION™ 6S BLX 4WD RTR. Capable of 80+ MPH speeds out of the box over on-road, dirt, and oval tracks, it now includes a handbrake and Spektrum® Smart electronics.

Looking for spare parts or upgrades?

View all spare parts


Features

  • Spektrum® 3-Channel DX3™ 2.4GHz DSMR® radio and SR6110AT Receiver with AVC® (Active Vehicle Control™)
    • Ergonomic steering wheel for precise control in all conditions
    • On-the-fly adjustable AVC® gain for personalized handling set-up
    • Convenient voltage level indicator for Spektrum® Smart batteries
    • Convenient handbrake button for on-demand drifting
  • Download the free Spektrum® Dashboard™ app for iOS or Android to:
    • Connect your mobile device wirelessly via Bluetooth to your DX3™ transmitter*
    • View real-time telemetry data including ESC temperature, receiver (BEC) voltage, drive pack voltage and motor RPM
    • * Requires Bluetooth module SPM6741, available separately
  • ARRMA® ADS-15M Steering Servo
    • Waterproof*
    • Metal-geared
    • 195 oz-in (15kg-cm) torque @ 6V
  • Spektrum® SPMS650 Brake Servo
    • Waterproof*
    • Plastic-geared
    • 83 oz-in (6kg-cm) torque @ 6V
  • Spektrum® Firma™ 150A Smart ESC
    • Waterproof*
    • Handles 4S/6S power
    • IC5® connectors (EC5™ compatible)
  • Spektrum® Firma™ 4074 2050Kv Brushless Motor with Safe-D pinion gears
  • New electronics module
    • Improved range
  • New handbrake feature
    • Mechanical rear brakes for stunts and drifting
    • Convenient DX3™ transmitter handbrake switch
    • Chassis handbrake module with vented disc brake
  • Fresh street body look with matte gloss effect designs
  • Tunable wing for customizing the downforce
  • Full-width front splitter balances downforce distribution
  • Rear diffuser increases downforce and grip for cornering faster and with confidence
  • Adjustable front and rear body mounts
  • 3mm Plate, 6061-T6 anodized aluminium chassis
  • Centre brace for maximum durability
  • Heavy-duty drivetrain with durable steel driveshafts throughout
  • High-speed centre driveshaft support
  • Rubber-shielded bearings
  • All-metal diff outdrives and gearbox internals
  • Updated internal gears with new tooth profile for increased strength
  • Lower internal gear ratio to reduce the centre line transmission RPM, reducing centre driveshaft resonance and increasing drivetrain durability
  • Oil-filled, adjustable, anodized aluminium shocks
  • Black-anodized aluminium front and rear shock towers
  • Waterproof* receiver box
  • Large battery trays
  • 5-spoke wheels
  • Durable wheel hubs
  • dBoots® Hoons™ all-road tires
  • 2-year limited warranty (see website for details)

* For details on waterproof standards, please refer to the product instruction manuals

You're reviewing:

Arrma Infraction BLX All-Road Truck, RTR, Silver, ARA7615V2T2

Your Rating

Video

Product Information

High-speed bashing with the Arrma Infraction

ARRMA INFRACTION 6S BLX RC Truck

The ready-to-run INFRACTION™ 6S BLX 4WD 1/7 scale truck tops off a tough and powerful ARRMA® brushless platform with stunning style — ideal for intermediate-level drivers who are eager to experience street bashing at 80+ MPH speeds (achievable in optimum conditions using a 6S LiPo and the included speed pinion gear). Its Spektrum® DX3™ radio and Smart brushless power system components provide real-time telemetry that also helps you reach and maintain maximum performance.

Another feature new to the INFRACTION™ 6S BLX 4WD is a handbrake. The chassis includes a module for a rear vented disc brake and a powerful Spektrum® SPMS650 brake servo. You control the handbrake from a convenient switch on the DX3 transmitter for thrilling drifting, “hooning” and stunt action.

With its 4X4 traction, you can run the INFRACTION™ 6S BLX 4WD on all roads, in all conditions — over loose gravel, asphalt, smooth dirt, and short grass, in the sun, rain, and ice — while enjoying fresh RESTO MOD looks. The street body arrives factory-finished with new matte gloss effect designs. The included tunable wing lets you customize the downforce just the way you want it.

To further enhance the aerodynamics, the chassis includes a full-width front splitter that balances downforce distribution. A rear diffuser increases downforce and grip, enabling you to corner faster and with confidence. Mounted on realistic 5-spoke wheels, the four dBoots® Hoons™ all-road tires keep their grip on the surface to pour on speed or stop on a dime.

New ARRMA Infraction

Street Bash looks, Arrma strength

Underneath those streamlined Street Bash looks is a chassis which proves to the world, once again, that ARRMA® builds the most durable bashers. The 6061-T6 anodized aluminium chassis houses a heavy-duty drivetrain with steel driveshafts, plus all-metal diff outdrives and gearbox internals. Updated internal gears feature a new tooth profile for increased strength. A lower internal gear ratio reduces the centreline transmission RPM, reducing the centre driveshaft resonance and increasing drivetrain durability. Chassis toughness is reinforced with a centre brace. Bearings are rubber-shielded, and the adjustable, oil-filled, anodized aluminium shocks are mounted on strong, black-anodized aluminium shock towers.

ARRMA® has equipped the ready-to-run INFRACTION™ 6S BLX 4WD with the 3-channel Spektrum® DX3™ radio and an SR6110AT receiver featuring AVC® (Active Vehicle Control™) technology for high-speed stability. A convenient voltage level indicator is built into the transmitter which lets you easily track on-board Smart battery power. This RC truck's brushless power system also features Spektrum® Firma™ Smart components, so it’s easy to receive real-time updates of ESC temperature, receiver (BEC) voltage, drive pack voltage and motor RPM. Just download the Spektrum® Dashboard™ app for iOS or Android, available for free at the App Store or Google Play.

What's in the box?

  • ARRMA® INFRACTION™ RETRO MOD STREET BASH 1/7 6S BLX 4WD RTR

  • Spektrum® DX3™ DSMR® Radio with SR6110AT Receiver

  • Spektrum® Firma™ 150A Smart ESC

  • Spektrum® Firma™ 4074 2050Kv Brushless Motor

  • ARRMA® ADS-15M Waterproof Steering Servo

  • Spektrum® SPMS650 Brake Servo

What you need

  • (2) 2S or 3S LiPo batteries
  • Compatible charger
  • Safe LiPo charging bag
  • (4) AA transmitter batteries

Specs

Completion Level
Ready-to-Run
Scale
1/7
Length
27.36 in (695mm)
Width
12.20 in (310mm)
Height
7.87 in (200mm)
Weight
11 lb (5kg)
Ground Clearance
0.59 in (15mm)
Wheelbase
15.98 in (406mm)
Front Track
12.13 in (308mm)
Rear Track
12.01 in (305mm)
Chassis
3mm Plate, 6061-T6 Aluminium
Suspension
Independent
Shock Type
3.03 in (77mm) FR, 3.43 in (87mm) RR. Aluminium
Drivetrain
4WD
Differential
Three oil-filled metal gear diffs
Wheel Type
5-Spoke, 17mm hex
Wheel Diameter
3.27 in Inner, 2.95 in Outer (83mm Inner, 75mm Outer)
Wheel Width
1.69 in (43mm)
Tyre Compound
White
Tyre Tread
Hoons™
Tyre Diameter
3.94 in (100mm)
Motor Type
Non-sensored Brushless
Motor Size
4074
Pinion
15T
Spur Gear
46T
Gear Pitch
1.0MOD
Internal Gear Ratio
2.8:1
Final Drive Ratio
8.58:1
Speed Control Included
Yes
Radio
Spektrum® DX3™ 3-Channel
Servos Included
Yes
Brakes
Metal disc with metal pads
Body
INFRACTION, Screen printed, decaled and trimmed
Ball Bearings
Transmission
Experience Level
Intermediate
Recommended Environment
All-Road
Is Assembly Required
No
Approximate Assembly Time
Less than 1 hour
