Blade Fusion 700 3D Helicopter Kit with Motor and Blades, BLH13075

As a testament to their performance and popularity, the Fusion series models have been available since 2018 and remain available with support and spare parts still available. Combining attributes such as quality, convenience, value and capabilities the top-of-the-line Blade Fusion 700 Kit represents an opportunity for pilots to enjoy years of development and know-how along with the choice of optimising their heli with parts that suit them.

The Pinnacle of Performance

Nearly two decades of engineering and development experience are packed into a rugged, high-quality carbon fibre and aluminium airframe that delivers high-level precision, sport and advanced 3D flying. The Blade Fusion 700 Kit's airframe design is quickly assembled and easy to repair and maintain. The 4735-540Kv brushless outrunner motor drives the Delrin helical main gear, bringing outstanding performance and torque when using the popular 12S or twin 6S 4000-5000mAh LiPo setups. Tail performance is locked in on every flight by a belt-driven aluminium-constructed tail assembly.

Blade Fusion 700 Combos Available

Included in the Blade Fusion 700 Kit is a brushless outrunner motor along with carbon fibre 105mm tail rotor and 700mm main rotor blades. You can then complete the kit with the servos, flight controller, ESC and receiver you choose. There are two money-saving Super Combos available (BLH13075C and BLH13075HPC) that include the best Spektrum components which include H6350 and H6360 brushless servos, a DSMX compatible receiver, an upgraded and updated FC6350HX flybarless control system, along with your choice of high voltage 120mAh or 200mAh Smart ESC's. Either combo is compatible with 4000-5000mAh 12S battery setups and a great choice for most pilots will be the 120A ESC version. If you're a world-class pilot looking for a bit extra, the 200A ESC can handle the most aggressive 3D manoeuvres possible.

Compatible parts for your Blade Fusion 700 Kit that are available separately include different tooth count tail drive pulleys, 4730-350Kv motor, and longer 115mm tail rotor blades all of which can enhance the particular type of flying you prefer. If you're after a different look there's an optional black landing gear and orange painted canopy plus carbon fibre tail fin available as well.

Not only will Blade Fusion 700 Kit owners enjoy the parts options available when first purchased, but there will also be ongoing support and long-term spare part availability. The Blade Fusion 700 Kit parts list are all available separately and, along with the helicopter, will be available for years to come like the Fusion 360, 480 and 550 RC helicopters before it.

If you're flying level is intermediate or above and you want your first 700-sized model, or, if you fly at an expert level already, the Blade Fusion 700 Kit offers you flexibility and performance along with ongoing support for your flying journey!

Mechanics Features

• Includes a 4735-540Kv outrunner motor compatible with popular 12S battery setups

• Precision machined Delrin® helical main gear with 11- and 12-tooth pinion gears

• Sprag autorotation clutch and machined rotor head dampers with o-rings

• High-strength steel 15mm main shaft and 10mm spindle/feathering shaft

• Black anodized aluminium swashplate and other components

• Aluminum blade grips with zero pitch indicator marks

• Includes 700mm carbon fibre main rotor blades

Frame Features

• All-metal and 2mm thick carbon fibre construction

• 2-piece white moulded landing gear plus a painted fibreglass canopy for excellent visibility

• Sliding carbon fibre battery tray with positive locking mechanism

• Reinforced machined aluminium main shaft bearing block assembly

Tail Features

• Ovalized aluminium tail boom for added strength and rigidity without boom supports

• Machined aluminium tail case and separate painted vertical fin for improved visibility

• 8mm wide drive belt with adjustable tension drives a large aluminium pulley

• Belt-driven tail rotor for lower weight, less parts, and easier maintenance

• 6mm high-strength steel tail shaft with metal bell crank, hub, and grips

• 5mm carbon fibre tail pushrod with ball links for precise control

• Hidden tail servo for added protection and a sleek look

• Includes 105mm carbon fiber tail rotor blades

Advanced Experience Required

Skill Level 4 aircraft, like this one, are suitable for RC pilots who already have experience with and the skills to assemble, set up, and fly similar class models. And although this is a perfect first-ever 700-sized model for intermediate pilots, you should have the experience and skills necessary to successfully assemble, set up, and fly other helicopter models like the Blade Fusion 480 and 550 before attempting to fly the Fusion 700.

What's in the box?

• (1) Blade Fusion 700 Helicopter Kit with:

  • (1) Spektrum Avian 4735-540Kv 10-Pole Brushless Outrunner Motor (included)

  • (1) Blade 700mm Carbon Fiber Main Rotor Blade Set (included)

  • (1) Blade 105mm Carbon Fiber Tail Rotor Blade Set (included)

  • (1) Foam Blade Holder  (included)

• (1) Product Manual
