E-Flite EC-1500 Twin Cargo RC Plane, BNF Basic, EFL15750
With a unique design that offers versatility, capability and fun, the E-flite EC-1500 is effectively a lot of different airplanes in one. Capable of sport flying, slow and scale-like flying, and, aggressive 3D aerobatic means the flight envelope on this RC plane has something for every pilot!
Looking for spare parts or upgrades?
Features
- Capable of slow and scale-like flying, sport flying and aggressive 3D aerobatics due to its unique and groundbreaking design
- Fly from various surfaces including grass, dirt, asphalt or even snow with the included optional use skis
- Using the optional float (EFLA550) and hardware set (EFL5771) you can fly from lakes and ponds and dams
- Custom 5-blade counter-rotating props propelled by high-power 3S and 4S compatible power systems
- More secure and easier propeller installation with updated design bolt-to-the-motor prop adaptors
- Using 4S batteries you have the power to hover and for unlimited vertical performance
- Large battery compartment in the top hatch that fits 3S 3200mAh to 4S 6400mAh LiPo batteries
- Spektrum Avian 40-amp Dual Smart Lite ESC gives pilot real-time ESC temp, battery voltage and other data via compatible transmitter and receivers
- Special ground handling and aerobatic capabilities are provided by differential thrust and reversing (BNF Basic version only)
- Added control and aerobatic capabilities from oversized control surfaces with double-bevelled hinge lines
- Functional flaps along with selectable size ailerons can travel both ways for optional use with crow and full-span flaperon/spoileron/aileron setups
- Servo-controlled, operational cargo door with 65 x 107mm opening with a cargo bay volume of almost 140 cubic inches
- Eight metal-geared factory-installed servos on all surfaces and on the functional cargo door
- Pocket or CA hinges on all control surfaces plus precise ball-link equipped linkages
- AR8360T Spektrum receiver with industry-leading DSMX technology and full range telemetry
- Optional use SAFE Select envelope protection technology that makes flying easier
- Locked in feel and unmatched stability provided by AS3X technology
- Factory installed fully functional LED navigation, strobe and landing lights
- Remove the magnetically secured nose cone to easily install a GoPro Hero or similar HD action cameras (cameras sold separately)
- An additional FPV camera mounting position on top of the magnetically secured large top hatch (FPV camera/gear sold separately)
- Includes panel lines, hatches and more surface details plus a scale-inspired fully painted finish
- Decal sheets included with Army, Air Force, Coast Guard, Marines and Navy markings
- Easy tool-free field assembly – thumbscrews to secure two-piece wing and hands-free connections
- Durable, lightweight, large, composite-reinforced EPO airframe
- Practice flying this model on the latest version of the RealFlight RC flight simulator
Reviews
Video
Product Information
The E-flite® EC-1500 Twin 1.5m has an incredible flight envelope capable of delivering everything from slow scale-like flying, and sport flying right through to aggressive 3D aerobatics. In other words something for a wide range of pilots! The optimized design of the E-flite® EC-1500 Twin 1.5m delivers capability, FUN and versatility and it feels like there are many different airplanes in one. You could be forgiven for thinking that because of its 1.5m wingspan that the E-flite® EC-1500 Twin is a little undersized. You would be wrong. Because of the large diameter fuselage, tail surfaces and wing chord and area, it will fly bigger than it may seem in writing. It's still light enough to perform with a composite-reinforced, extremely durable and lightweight EPO airframe.
Uniquely capable and versatile RC plane
The brushless outrunner motors on the twin power systems turn the custom five-blade counter-rotating propellers that can be much more securely and easily installed due to the updated bolt-to-the-motor prop adapters. With a 3S 3200-6400mAh LiPo battery hooked up to this setup, you get excellent performance. However, if you want to get unlimited vertical capability and be able to hover you can install a 4S LiPo without the need for any modifications. The twin motors are paired with the Spektrum 40-amp Avian Dual Smart ESC that can deliver the pilot a variety of real-time telemetry data regarding the power system with either Smart or non-Smart batteries with compatible receivers including the Spektrum AR8360T installed in the BNF Basic version of the E-flite® EC-1500 Twin 1.5m. You will also need to have a Spektrum AirWare equipped transmitter. This telemetry data includes ESC temperature, battery voltage levels plus much more.
The E-flite® EC-1500 Twin 1.5m is equipped with differential thrust and motor reversing to assist with ground handling. Optional use SAFE Select technology along with AS3X technology makes flying the E-flite® EC-1500 Twin 1.5m a lot easier. The eight-channel AR8360T Spektrum receiver along with functional flaps and selectable-size ailerons that can travel both ways also allow you multiple wing configuration options – including "crow” and/or full-span flaperon/aileron/spoileron setups.
Functional scale details including a cargo door
The servos on the control surfaces are all metal geared and amongst the eight factory-installed servos on the E-flite® EC-1500 Twin 1.5m. The fully functional cargo door is also controlled by one of these servos which allows you to carry and drop payloads of your choosing from the large cargo bay. Fly from dawn until dusk with realistic LED navigation, landing and simulated strobe lights powered by the flight battery. Take off and land on a variety of surfaces including snow (skis included). You also have the option of flying from water with optional floats sold separately.
Aerial filming and photography are enabled by the magnetically secured nose cone on the E-flite® EC-1500 Twin 1.5m which allows you to install a GoPro or similar camera (sold separately) or you have the option of mounting a separate FPV camera on the large top hatch. There is a range of decals included with the E-flite® EC-1500 Twin 1.5m allowing you to customize the fully painted grey finish with US Air Force, Army, Coast Guard, Navy, and Marines along with other markings for additional personalisation. All up the E-flite® EC-1500 Twin 1.5m is a versatile, capable and fun fly for intermediate to experienced pilots interested in a range of different flying options.
Designed for intermediate to experienced RC pilots
The BNF Basic version of the E-flite® EC-1500 Twin 1.5m is a Skill Level 2 RC aircraft meaning it is suitable for RC pilots who already have the skills and experience to assemble/set up/fly similar class models. Although it is equipped with optional-use SAFE Select it is not suitable for beginners, or a next step after a trainer model for low-hours RC pilots, or, a first 3D capable model for intermediate pilots. You should have the experience and skills necessary to successfully fly higher performance, 3D capable and/or twin-powered models like the E-flite Twin Timber 1.6m, Timber X 1.2m, Extra 300 3D 1.3m, Ultra Stick 1.1m, or other similar class models before attempting to fly the EC-1500 Twin 1.5m.
It is also available in a Plug-N-Play Completion Level.
What's in the box?
-
(1) E-flite® EC-1500 Twin 1.5m
-
(1) Spektrum™ Servo (installed)
-
(7) Spektrum Metal-Geared Servos (installed)
-
(2) Spektrum Brushless Outrunner Motors (installed)
-
(1) Spektrum Avian™ Dual 40A Brushless Smart Lite ESC (installed)
-
(1) Spektrum AR8360T 8-Channel Receiver (installed) (BNF Basic version only)
-
(1) Product Manual
What you need
- Full-range 6–8+ channel Spektrum™ DSMX®/DSM2® compatible transmitter
- 3S 11.1V or 4S 14.8V 3200–6400mAh LiPo with EC3™ or IC3™ Connector
- Compatible LiPo charger
Specs
- Completion Level
- Bind-N-Fly Basic
- Wingspan
- 60.12" (1527 mm)
- Servos
- Included
- Motor Size
- 3720-650Kv 14-Pole (x2)
- Product Length
- 46.85" (1190 mm)
- Speed Control
- Included
- Material
- EPO
- Minimum Required Radio
- Full-range 6+ channel Spektrum™ DSMX®/DSM2® compatible transmitter
- Product Weight
- 97.2oz (2755g) with Recommended Battery
- Technology
- Smart, AS3X and SAFE
- Connector Type
- IC3
- Approximate Assembly Time
- Less than 1 Hour
- Power Type
- Electric
- Radio
- Sold Separately
- Skill Level
- Level 2
- Recommended Motor Battery
- 14.8V 4000mAh 4S 30C Smart LiPo Battery with IC3 Connector
- Motor Type
- Brushless
- Propeller Size
- 10 x 9, 5-Blade
- Battery
- Sold Separately
- LiPo Compatibility
- 3S, 4S
- Charger
- Sold Separately
- Flaps
- Yes
- Receiver
- Included
