AXI03006T1

Axial SCX10 III Jeep JT Gladiator RC Crawler, RTR, Gray, AXI03006T1

$929.99
ETA Jun 14
up
down

The scale crawling playing field has changed now that the SCX10 III Jeep JT Gladiator RTR from Axial has arrived. Upgraded from the proven SCX10 platform, this RC Crawler offers a larger 355mm wheelbase to accommodate a more realistic body and a DIG function to get you up, over and through your favourite crawling obstacles.

Looking for spare parts or upgrades?

View all spare parts


Features

  • 2.4GHz DX3 DSMR Spektrum radio provides advanced response, interference resistance, and, range, and is fully compatible with Spektrum Smart technology provided by the Spektrum Firma 40 ESC/Receiver
  • 355mm wheelbase with longer frame rails and chassis allow for a more realistic Jeep JT Gladiator body
  • Three-piece realistic Jeep JT Gladiator body that features injection-moulded scale parts including door handles, hood vents, bed rack, mirrors and more
  • Transfer case cover and transmission housing protect the replica V8 engine, improve scale appearance and add forward-mounted weight
  • Centred battery tray that accepts full-size NiMH or LiPo’s with side pod space to run smaller “shorty” LiPos
  • Lock the rear axle from your transmitter with the DIG function which enables a tighter turning circle from front wheel drive
  • Optional two-speed transmission that increases vehicle speed by around 40%
  • Run DIG and two-speed transmission simultaneously with the addition of a micro servo and 4-channel receiver (sold separately)
  • New AR45 Portal Axles have an offset front housing to add to the realistic looks, increase ground clearance and a universal that gives 45 degrees of steering
  • Hypoid gears are included on the differential locker allowing for smaller size gears, improved gear reduction and reducing torque twist
  • New O-ring material feature on the oil-filled shocks for a better seal and cap with bleed screw for easier rebuilds
  • Stronger materials increase stiffness and durability
  • Detailed interior and moulded driver that adds to the scale realism
  • Simple body removal thanks to new rear body mounts
  • 15kg, high torque metal geared waterproof servo allows you to drive confidently when the weather and conditions aren’t ideal
  • Floor sides and inner fenders reduce visibility of internal components from the side
  • Improved materials increase durability and stiffness while holding tighter tolerances to eliminate most “slop”.
  • Metal stainless steel pivot balls at all suspension points increase durability and wear life for consistent handling.
  • All-metal drive train components in the transmissions, portals and axle gears — with pinion gear included, the vehicle has 23 metal gears in total
  • Remove and replace tyres with no glue with the 3-piece beadlock wheels
  • Increased ground grip and clearance with taller officially licensed Nitto Trail Grappler tyres
  • Improved suspension geometry reduces torque twist while allowing chassis fine-tuning
You're reviewing:

Axial SCX10 III Jeep JT Gladiator RC Crawler, RTR, Gray, AXI03006T1

Your Rating

Video

Product Information

Next-level off-road scale action with the Axial Jeep JT Gladiator

Jeep JT Gladiarot replica

Off-road scale action has taken another leap forward with the release of the 1/10th scale Axial SCX10 III Jeep JT Gladiator 4WD RTR. The SCX10 III chassis keeps key features of the successful SCX10 platform while making improvements that will take your RC Crawling to the next level. The chassis realism on the Axial SCX10 III Jeep JT Gladiator 4WD RTR gives you a replica V8 engine housing where the brushless motor is installed, giving the chassis forward-mounted weight. This is paired with a scale detailed transfer case and transmission housing like its full-scale counterpart. This RC crawler gives you the advantages of Spektrum Smart technology as it comes with a 2.4GHz DX3 3-channel DSMR transmitter and the 40A Firma ESC/Receiver combo as the standard radio system. To enhance your Smart Technology experience, you can install a Smart LiPo battery that allows you to view the charge capacity you have left on the voltage level indicator on the DX3 transmitter. You can go all out and fit out your DX3 with the Spektrum BT2000 Bluetooth module, download the Spektrum Dashboard free app and you can start using real-time telemetry without the need for modules or sensors on board.

The Axial SCX10 III Jeep JT Gladiator’s transmission arrives set up with a DIG function that allows you to lock the rear axles, giving you a front-wheel-drive and a tighter turning radius to get you up and over challenging obstacles. Alternatively, instead of having the DIG function, you can set-up a two-speed transmission where you can increase the rock crawler's speed by 40%. You can have access to both of these features simultaneously by adding another micro servo and using a radio with another channel – like the Spektrum DX5.

RC Rock Crawler

The new AR45 portal axles on the SCX10™ III Jeep® JT Gladiator feature portal gears for increased ground clearance, offset front housing for a more authentic look and universals that offer 45 degrees of steering. Additionally, tried-and-true Hypoid gears are included on the differential locker allowing for smaller size gears while improving gear reduction at the axle and reducing torque twist. When it comes to batteries, the Axial SCX10™ III Jeep® JT Gladiator gives you options. Not only does the standard battery tray - positioned near the centre of the chassis for better balance - accept full-size NiMH or LiPo batteries, you are able to use “shorty” LiPo packs in the side pods provided. The normally visible internal components are hidden with floor sides and inner fenders give a cleaner/more scale look.

The three-piece authentic looking body of the Jeep JT Gladiator sits atop the chassis and has over 20 injection-moulded parts including a bed rack, door handles, mirrors, hood vents and more — taking polycarbonate body realism to the next level. Adding additional scale realism and giving you higher clearance and more grip when it matters is the taller and wider R35 compound, officially-licensed Nitto Trail Grappler tyres that come mounted on 3-piece Beadlock wheels.

What's in the box?

  • (1) Axial® SCX10™ III Jeep® JT Gladiator 4WD

  • (1) Spektrum™ DX3™ DSMR® Radio

  • (1) Spektrum Firma™ Smart 40A ESC/Receiver (installed)

  • (1) Spektrum 15kg Servo (installed)

  • (1) Product manual

What you need

  • Vehicle Battery (accepts standard and shorty packs)
  • Compatible charger

Specs

Type
"Scale" 4x4 Crawler
Completion Level
Ready-to-Run
Scale
1/10
Length
22.25 in (565 mm)
Width
9.25 in (234 mm)
Height
9.5 in (241 mm)
Weight
7 lb (3.175 kg)
Ground Clearance
3 in (76.2 mm)
Wheelbase
14 in (356 mm)
Track
8.9 in (226 mm)
Front Track
8.9 in (226 mm)
Rear Track
8.9 in (226 mm)
Chassis
Adjustable Steel C-channel
Suspension
Multi-Link Solid Axle
Shock Type
Oil-Filled/Coil-Over Spring
Drivetrain
4WD (locked front and rear)
Differential
Locked
Wheel Type
Injection Moulded 3-Piece Beadlock
Wheel Diameter
1.9 in (48.3 mm)
Wheel Width
1 in (25.5 mm)
Tyre Compound
R35 (sticky)
Tyre Tread
Nitto Trail Grappler M/T
Tyre Diameter
4.7 in (119 mm)
Motor Type
Brushed
Motor Size
540
Pinion
14T
Gear Pitch
32-Pitch
Final Drive Ratio
45.6:1 Low / 31.3:1 High
Speed Control Included
Y
Radio
Spektrum
Servos Included
Y
Body
Polycarbonate
Ball Bearings
Complete Vehicle
Experience Level
Beginner
Recommended Environment
All-Terrain
Is Assembly Required
No
